420 Powder Packaging Machine

Yueyang Smile Packing Equipment&Material Co.,Limited is a company specialized in packing materials and related products for the coffee and tea. Since its inception in 2014, The company has cooperated with many clients both from domestic and overseas, and has obtained consistently high praise from our customers since it was set up.. The company holds the managerial idea that ‘Quality Proves Strength, Details Reach to Success’, and tries its best to do well at any aspect from each stitch, each point of procedure of manufacturing to final inspection, packing and shipment. We insist on the principle of development of 'High quality, Efficiency, Sincerity and Down-to-earth working approach' to provide you with excellent service of processing! We sincerely welcome you to visit our company or contact us for cooperation!

Description

420 powder packaging machine



Performance characteristics

The use of screw machine to complete the measurement, filling, nitrogen filling and so on. Suitable for the measurement of those powder materials that are easy to flow or have poor flowability;

Servo drive system, high precision, stable performance and other advantages;

Using PLC servo system, pneumatic control system, large display touch screen to form the drive control core; maximize the control precision, reliability and intelligence of the whole machine;

Stainless steel open-type bins are easy to clean;

equipped with security protection, in line with corporate security management requirements;

Using intelligent temperature controller, accurate temperature control, ensure that the sealing is beautiful and smooth;

Using PLC double-drawing structure paper feeding system, sealing and cutting position are all using motor automatic correction device, large display touch screen mechanism drive control core, to maximize the entire control accuracy, reliability and intelligence;

The machine and metering support can automatically complete the product packaging, feeding, filling bag, inflate (exhaust), date printing all the packaging process, and automatically complete the count;

Fault display system is provided to help eliminate faults in time;

According to customer needs can be made pillow-shaped bags, hanging hole bags;

There are all stainless steel models and carbon steel spray models to choose from.

Scope of application: It is suitable for the automatic measurement of powdered materials such as milk powder, rice flour, milk tea powder, protein powder and seasoning.

Applicable packaging materials: OPP/PE, PET/VM, PET/PE, OPP/CPP and other composite materials.

Optional equipment: dust suction device, gusseting device.

Technical Parameters:

Model QC-420L QC-520L

Bag size L:80-300mm W:80-200mm L:100-350mm W:100-250mm

Packing speed 25-75bags/min 25-65bags/min

Package Weight/Accuracy Weight 100g≤±1g Weight 100-500g≤±1% Weight 500g≤±1g

Power Supply and Power 220V 50-60Hz 3.0Kw 380/220V 50-60Hz 3.6Kw

Compressed air usage 6-8Kg/m2, 0.15m3/min 6-8Kg/m2, 0.15m3/min

The weight of the whole machine 650-750Kg 850-950Kg

Dimensions L1450×W1000×H2700(mm) L1450×W1200×H2800(mm)


Welcome to wholesale the 420 powder packaging machine with our professional manufacturers and suppliers in China. We will offer you the best quality products, cheap price and satisfactory service.
